| PERFORMANCE |
| Processor | Intel® Core™ i7-14700T, 20C (8P + 12E) / 28T, Max Turbo up to 5.2GHz, P-core 1.3 / 5.0GHz, E-core 0.9 / 3.7GHz, 33MB |
| Graphics | Integrated Intel® UHD Graphics 770 |
| Chipset | Intel® Q670 Chipset |
| Memory | 1x 16GB SO-DIMM DDR5-5600 |
| Memory Slots | Two DDR5 SO-DIMM slots, dual-channel capable |
| Max Memory | Up to 64GB (2x 32GB DDR5 SO-DIMM) |
| Storage | 512GB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal 2.0 |
| Storage Support | Up to two drives, 2x M.2 2280 SSD
• M.2 2280 SSD up to 2TB |
| Card Reader | No card reader |
| Optical | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC233 codec |
| Speakers | Premium, 2Wx1 |
| Power Supply | 135W 90% Adapter |
| DESIGN |
| Keyboard | USB Traditional Keyboard, Black, Czech / Slovak |
| Mouse | USB Calliope Mouse, Black |
| Expansion Slots | - One PCIe® 4.0 x8, low-profile
- Two M.2 PCIe® Gen 4x4 slots (for SSD)
- One M.2 slot (for WLAN)
|
| Case Color | Black |
| Stand | None |
| Adapter Cage | None |
| Toolless Chassis Screw | Toolless Chassis Screw |
| Dust Filter | None |
| Mounting | 1x VESA Mount |
| IO Box | None |
| Pen | Pen Not Supported |
| Form Factor | Tiny (1L) |
| Dimensions (WxDxH) | 179 x 182.9 x 36.5 mm with rubber feet (7.05 x 7.2 x 1.44 inches with rubber feet) |
| Weight | 1.25 kg (2.76 lbs) |
| CONNECTIVITY |
| Ethernet | Integrated 100/1000M |
| WLAN + Bluetooth | Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3, vPro® |
| WWAN | Non-WWAN |
| Front Ports | - 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 1x headphone / microphone combo jack (3.5mm)
|
| Optional Front Ports (configured) | None |
| Rear Ports | - 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), with Smart Power On
- 2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 1x HDMI® 2.1 TMDS
- 1x DisplayPort™ 1.4a (HBR2, DSC)
- 1x Ethernet (GbE RJ-45)
|
| Optional Rear Ports (configured) | 1x DP |
| SECURITY & PRIVACY |
| Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Fingerprint Reader | No fingerprint reader |
| Physical Locks | Kensington® Security Slot™, 3 x 7 mm |
| Chassis Intrusion Switch | Chassis Intrusion Switch |
| MANAGEABILITY |
| System Management | Intel® vPro® Enterprise |
| SERVICE |
| Base Warranty | 3-year, Onsite |
| Included Upgrade | 3Y Premier Support TC DT/AIO WHB (CPN) |
| CERTIFICATIONS |
| Green Certifications | - ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 3
- RoHS compliant
- TCO Certified 9.0
|
| Mil-Spec Test | MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog) |
| SOFTWARE |
| Operating System | Windows® 11 Pro, Czech / Slovak / English |
| Bundled Software | None |
| ACCESSORIES |
| Bundled Accessories | None |
| MODEL INFORMATION |
| Model | 12TH002FCK |
| Country/Region | Czech, Slovakia |
| TopSeller | Yes |
| EAN / UPC / JAN | 0198155314360 |
| Announce Date | 2024-09-17 |
| End of Support | 2031-02-23 |
