Ubiquiti Professionalgrade 32port, Layer 3 Etherlighting™ switch for highcapacity 25G SFP28 connections

Overview Dimensions 442.4 x 43.7 x 480 mm (17.4 x 1.7 x 18.9") Port Layout 25G SFP28 32 (25G/10G/1G) Redundancy DC Power Backup Layer 3 ? Form Factor Rack Mount (1U) Etherlighting™ ? Performance Switching Capacity 1.6 Tbps Total Non-Blocking Throughput 800 Gbps Forwarding Rate 1.2 Bpps Supported VLANs 1,000 MAC Address Table Size 32,000 L3 Table Size ARP Entries 128,000 IPv4 Routes 256,000 Packet Buffer Size 8 MB Layer 3 Features DHCP Server (Local Networks) ? DHCP Relay ? Inter-VLAN Routing (Local Networks) ? Static Routing (Local Networks) ? Layer 2 Features LACP Port Aggregation ? STP & RSTP ? Advanced IGMP Configuration (Querier, Fast Leave, Router Port) ? IGMP Snooping ? 802.1X Control ? MAC-Based ACLs & Device Isolation ? DHCP Snooping & Guarding ? Egress Rate Limit ? Flow Control ? Storm Control ? Multicast & Broadcast Rate Limiting ? MAC Address Blocking ? IP-Based ACLs & Network Isolation ? MAC-Based Port Restriction ? Port Isolation ? Port Mirroring ? Jumbo Frames ? LLDP-MED ? Voice VLAN ? Loop Protection ? Hardware Max. Power Consumption 200W Power Method (1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input Power Input Method AC input Power Supply AC/DC, internal, 200W Supported Voltage Range 100—240V AC Management Ethernet AR Weight 7 kg (19.8 lb) Enclosure Material SGCC steel Mount Material SGCC steel Supported Rack Depth 482.6 mm (19") four-post racks Posts depths ranging from 600 to 1,066 mm (23.6-42”) LCM Display 1.3" touchscreen ESD/EMP Protection Air: ± 12kV, contact: ± 8kV Ambient Operating Temperature -5 to 40° C (23 to 104° F) Ambient Operating Humidity 10 to 90% noncondensing Etherlighting™ SFP28 ? LEDs RPS ? NDAA Compliant ? Certifications CE, FCC, IC
