SUPERMICRO PCIe x8 Add-On Card for up to four M.2 NVMe SSDs

Add-on Card Supermicro PCI-E 3.0 carrier card for up to four NVMe M.2 SSDs The Supermicro AOC-SHG3-4M2P M.2 NVMe SSD carrier AOC features four internal sockets for 4 different lengths of M.2 SSD coupled with an on-board switch allowing dense storage with intense performance. Designed for flexibility, this AOC fits a standard PCI-E 3.0 x8 slot and will require minimal, if any, BIOS or OS modifications to work instantly. This robust add-on card will address the growing demand for increased storage performance and scalability for a diverse range of solutions; from entry-level SMB systems to enterprise class server platforms. Ideal for embedded/IPC solutions and desktop/gaming station solutions, NVMe SSDs outperform current SAS/SATA SSDs several times over. Form factor: PCI-E 3.0 x8 full-height (FH). Includes both tool-less and metal adjustable stand-offs that can support four standard M.2 lengths: 22x110mm 22x80mm 22x60mm 22x42mm This product is only available through Supermicro. Compliance RoHS RoHS Compliant 6/6, Pb Free Key Features • Supports up to 4 NVMe M.2 SSDs • Standalone NVMe M.2 carrier • Supports 10°C - 50°C with sufficient airflow • OS Support : Windows, Linux • Operating Temp: 0° to 55°C Dimensions H x L 4.4" x 7.5" Validated Platforms Servers/Serverboards SYS-6029U-TR4T SYS-7049GP-TRT SYS-E403-9D-16C-FN13TP X10DGQ X11DPG-QT X11DPU X11SDW-16C-TP13F X11SSZ-F
