| PERFORMANCE |
| Processor | Intel® Core™ i9-14900, 24C (8P + 16E) / 32T, Max Turbo up to 5.8GHz, P-core 2.0 / 5.4GHz, E-core 1.5 / 4.3GHz, 36MB |
| AI PC Category | AI-Ready Workstations |
| Processor Sockets | 1x FCLGA1700 |
| Integrated Graphics | Integrated Intel® UHD Graphics 770 |
| Discrete Graphics | 1x NVIDIA® RTX 4000 SFF Ada Generation 20GB |
| Chipset | Intel® W680 Chipset |
| Memory | 2x 16GB SO-DIMM DDR5-4800 Non-ECC |
| Memory Slots | Four DDR5 SO-DIMM slots, dual-channel capable |
| Max Memory | Up to 192GB (4x 48GB DDR5 SO-DIMM) |
| PCIe NVMe Controller | Integrated NVMe® controller |
| PCIe NVMe Drive | 1x 1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal |
| SATA Controller | Integrated SATA controller |
| SATA/SAS Drive | None |
| Storage Support | Up to 1x 2.5" HDD or SSD + 2x M.2 SSD
• 2.5" HDD up to 1TB
• 2.5" SSD up to 7.68TB
• M.2 SSD up to 4TB each |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC897-Q codec |
| Power Supply | 300W 90% Adapter |
| DESIGN |
| Keyboard | USB Traditional Keyboard, Black, Czech / Slovak |
| Mouse | USB Calliope Mouse, Black |
| Expansion Slots | Two PCIe® slots with one PCIe 4.0 x16 and one PCIe 3.0 x8.
• Slot 1: PCIe 4.0 x16 (via MXM to PCIe riser card), low profile, 75W, double-width
• Slot 2: PCIe 3.0 x8 (x4 lanes), low profile, 25W |
| Bays | 1x 2.5" disk bay (optional, comes with disk) |
| Dust Filter | None |
| Dimensions (WxDxH) | 87 x 223 x 202 mm (3.43 x 8.78 x 7.95 inches) |
| Weight | 3.6 kg (7.94 lbs, maximum configuration) |
| CONNECTIVITY |
| Onboard Ethernet | Intel® I225-LM + I210-AT, 2x RJ-45, 2.5GbE + GbE |
| Optional Ethernet | None |
| WLAN + Bluetooth | Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.1, vPro® |
| Front Ports | - 2x Thunderbolt™ 4
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 1x headphone / microphone combo jack (3.5mm)
|
| Rear Ports | - 4x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 3x DisplayPort™ 1.2
- 1x Ethernet (2.5GbE RJ-45)
- 1x Ethernet (GbE RJ-45)
|
| Optional Rear Ports (configured) | 4x miniDP 1.4a on NVIDIA® RTX 4000 SFF Ada Generation |
| SECURITY & PRIVACY |
| Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Physical Locks | Kensington® Security Slot™, 3 x 7 mm |
| Chassis Intrusion Switch | Chassis Intrusion Switch |
| MANAGEABILITY |
| System Management | Intel® vPro® Enterprise with Intel AMT 16 |
| SERVICE |
| Base Warranty | 3-year, Onsite |
| Included Upgrade | 1Y Premier Support from 3Y Onsite Windchill bundles (CPN) |
| CERTIFICATIONS |
| Green Certifications | - ENERGY STAR® 8.0, EPEAT™ Gold Registered
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- RoHS compliant
- TCO Certified 9.0
|
| ISV Certifications | |
| Mil-Spec Test | MIL-STD-810H military test passed |
| SOFTWARE |
| Operating System | Windows® 11 Pro, Czech / Slovak / English |
| Bundled Software | None |
| MODEL INFORMATION |
| Model | 30HA0040CK |
| Country/Region | Czech, Slovakia |
| TopSeller | Yes |
| EAN / UPC / JAN | 0197531843913 |
| Announce Date | 2024-02-27 |
| End of Support | 2031-05-24 |
