| PERFORMANCE |
| Processor | Intel® Core™ i5-13420H, 8C (4P + 4E) / 12T, P-core 2.1 / 4.6GHz, E-core 1.5 / 3.4GHz, 12MB |
| Graphics | Integrated Intel® UHD Graphics |
| Chipset | Intel® SoC Platform |
| Memory | 1x 16GB SO-DIMM DDR5-5200 |
| Memory Slots | Two DDR5 SO-DIMM slots, dual-channel capable |
| Max Memory | Up to 64GB DDR5-5200 |
| Storage | 512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal |
| Storage Support | Up to two drives, 2x M.2 SSD
• M.2 SSD up to 1TB each |
| Card Reader | No card reader |
| Optical | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC623-CG codec |
| Speakers | 1Wx1 |
| Power Supply | 180W 85% |
| DESIGN |
| Keyboard | USB Calliope Keyboard, Black, Czech / Slovak |
| Mouse | USB Calliope Mouse, Black |
| Expansion Slots | - One PCIe® 4.0 x16, low-profile, length ? 155mm, height ? 70mm
- One PCIe® 3.0 x1, low-profile, length ? 155mm, height ? 70mm
- Three M.2 slots (one for WLAN, two for SSD)
|
| Case Color | Chassis: Black, Bezel: Grey |
| Stand | None |
| Pen | Pen Not Supported |
| Form Factor | SFF (8.2L) |
| Dimensions (WxDxH) | 92.5 x 291.7 x 339.5 mm (3.6 x 11.5 x 13.4 inches) |
| Weight | Around 4.63 kg (10.2 lbs) |
| CONNECTIVITY |
| Ethernet | Integrated 100/1000M |
| WLAN + Bluetooth | None |
| WWAN | Non-WWAN |
| Front Ports | - 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports | - 2x USB-A (Hi-Speed USB / USB 2.0)
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On
- 1x HDMI® 2.1 TMDS
- 1x VGA
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) | None |
| Monitor Cable | None |
| SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 integrated in SoC |
| Physical Locks | - Kensington® Security Slot™
- Padlock Loop
|
| Smart Cable Clip | None |
| Chassis Intrusion Switch | None |
| Additional Security | None |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Onsite from 1Y Courier/Carry In SEE (CPN) |
| CERTIFICATIONS |
| Green Certifications | TCO Certified |
| SOFTWARE |
| Operating System | None |
| Bundled Software | None |
| ACCESSORIES |
| Bundled Accessories | Slim ODD Bracket Kit |
| MODEL INFORMATION |
| Model | 13DK003SCK |
| Country/Region | Czech, Slovakia |
| TopSeller | Yes |
| EAN / UPC / JAN | 0198156343987 |
| Announce Date | 2024-12-31 |
| End of Support | 2031-07-31 |
