PERFORMANCE | |
Processor | Intel® Core™ i5-8365UE (4C / 8T, 1.6 / 4.1GHz, 6MB) |
Graphics | Integrated Intel® UHD Graphics 620 |
Chipset | Intel® SoC Platform |
Memory | 1x 8GB SO-DIMM DDR4-2400 |
Max Memory | Up to 64GB DDR4-2400 |
Memory Slots | Two DDR4 SO-DIMM slots, dual-channel capable |
Storage | 256GB SSD 2.5" SATA6Gb/s |
Storage Support | Up to two drives, 1x 2.5" HDD/SSD + 1x M.2 SSD
• 2.5" SSD up to 256GB
• M.2 SSD up to 2TB |
Power Supply | None |
DESIGN | |
Keyboard | USB Calliope Keyboard, Black, Czech / Slovak |
Mouse | USB Calliope Mouse, Black |
Case Color | Black |
Dust Filter | None |
Mounting | 1x DIN Rail Bracket |
Dimensions (WxDxH) | 179 x 182.9 x 72 mm (7.05 x 7.20 x 2.83 inches) |
Weight | Around 2.985 kg (6.58 lbs) |
CONNECTIVITY | |
Ethernet | Integrated 100/1000M (2x RJ45) + I350-T4 (4x RJ45) |
WLAN + Bluetooth | Intel® 9560, Wi-Fi® 5, 802.11ac 2x2 + BT5.1 |
WWAN | Non-WWAN |
Front Ports |
|
Optional Front Ports (configured) | None |
Rear Ports |
|
Optional Rear Ports (configured) | None |
Monitor Cable | None |
SECURITY & PRIVACY | |
Security Chip | Discrete TPM 2.0, TCG certified |
SERVICE | |
Base Warranty | 3-year, Onsite |
Included Upgrade | None |
ENVIRONMENTAL | |
Operating Temperature | Wide Temperature 0? to 50? (32? to 122?) |
CERTIFICATIONS | |
Green Certifications |
|
SOFTWARE | |
Operating System | Windows® 10 IoT Enterprise 64 LTSC 2019, Czech / Slovak / English |
ACCESSORIES | |
Bundled Accessories | None |
