Displej - povrch
Matný
Displej - dotykový
Ne
Konektor RJ45
Ano
Konektor DVI
Ne
Ne
Konektor VGA (D-Sub)
Ne
Hmotnost přesná (kg)
8,79
Modelová řada
Dell UltraSharp
Model
U3824DW
Způsob použití
Domácí/Kancelářské
Dotyková obrazovka
Ne
Úhlopříčka (")
37,52
Úhlopříčka rozsah
33 - 40
Rozlišení
3840 x 1600
Počet pixelů na šířku
3840
Počet pixelů na výšku
1600
Rozteč bodů (mm)
0,22908
Formát obrazu
Panorama 21:9
Displej - typ
LCD IPS/PLS
Povrch displeje
Matný
Prohnutý monitor
Ne
LED podsvícení
Ano
Jas (cd/m2=nits) - přesný
300
Jas (cd/m2=nits) - rozsah
251 - 400
Kontrast (statický)
2000:1
Doba odezvy (ms)
8
Obnovovací frekvence (Hz)
60
Pozorovací úhel ver./ hor.
178 / 178
Výškově nastavitelný stojan
Ano
Pivot
Ne
Hmotnost (kg)
8,79
Montáž na stěnu
Ano
Barevná hloubka
1073 milionu
PIP (Picture in Picture)
Ano
Rozměr VESA uchycení (mm)
100 x 100 mm
Spotřeba energie (W)
35
Výkon repro (W)
18 W
Hmotnost rozsah (kg)
od 5,1 - 10
VESA standard
Ano
Power Delivery
Ano
Výkon Power Delivery (W)
90W
Konektor 15 Pin D-Sub
Ne
Konektor DisplayPort
Ano
DP/mini DP (počet)
1
Konektor HDMI
Ano
Verze HDMI
Verze 2.2
Konektor USB
Ano
Konektor SCART
Ne
Konektor USB-C
Ano
Konektor LAN RJ-45
Ano
Třída energetické účinnosti
G
FreeSync
Ne
FreeSync 2
Ne
G-Sync
Ne
Repro
Ano
Barva
Černá
Černá
Záruka
3 Roky
Daisy Chain
Ano
Celkový výkon repro (W)
18
EKO produkt podle parametru EU
Ano
TCO Certified
Ano
TCO Certified number
DE22104063
UltraSharp 38 Curved USB-C Hub Monitor – U3824DW
TECHNICAL SPECIFICATION:
DIAGONAL VIEWING SIZE: 952.90 mm (37.52 inches)
PRESET DISPLAY AREA (H X V): 879.67 mm x 366.53 mm (34.63” x 14.43”)
PANEL TYPE: IPS Black Technology
DISPLAY SCREEN COATING: Anti-Glare with 3H hardness
MAXIMUM PRESET RESOLUTION: 3840 x 1600 at 60 Hz
VIEWING ANGLE: 178° vertical / 178° horizontal
PIXEL PITCH: 0.22908 mm x 0.22908 mm
PIXEL PER INCH (PPI): 110.87
CONTRAST RATIO: 2000 to 1 (typical)
ASPECT RATIO: 21:9
BACKLIGHT TECHNOLOGY: White LED Edgelight System
BRIGHTNESS: 300 cd/m2 (typical)
TCO Certified: Yes
COLOR GAMUT:
• DCI-P3 98%
• Display P3 98%
• sRGB 100%
• REC. 709 100%
• 1.07 billion colors
RESPONSE TIME: 8 ms (Normal), 5 ms (Fast)
HDR READY: No
CONNECTIVITY:
• 1 x DP 1.4 (HDCP2.2) (supports up to WQHD+ 3840 x 1600 60 Hz)
• 2 x HDMI port (HDCP2.2) (supports up to WQHD+ 3840 x 1600 60 Hz TMDS as per specified in HDMI 2.1)
• 1 x USB Type-C upstream port (video and data) (Alternate mode with DisplayPort 1.4, Power Delivery up to 90W)
• 1 x USB-C upstream port (data only, 10 Gbps USB 3.2 Gen2)
• 4 x Super speed USB 10 Gbps (USB 3.2 Gen2) Type-A downstream port
• 2 x Super speed USB 10 Gbps (USB 3.2 Gen2) Type-C downstream port with charging capability at 15W (maximum)
• 1 x Super speed USB 10 Gbps (USB 3.2 Gen2) Type-A with BC1.2 charging capability at 2 A (maximum)
• 1 x Audio line-out port
• 1 x RJ45 2.5G port
ADJUSTABILITY: Height adjustable (120 mm), Tilt (-5° to 21°), Swivel (-30° to 30°), Slant adjust (-4° to 4°)
PBP/PIP: PbP (Yes), PiP (Yes)
KEYBOARD, VIDEO AND MOUSE (KVM): Yes, KVM and Auto-KVM
DAISY CHAIN AVAILABILITY: No
AUDIO OUTPUT: 1 x Audio line-out
BUILT-IN SPEAKER: 2 x 9W
DELL DISPLAY MANAGER: Yes, Easy Arrange, Other key features
SPECIFICATIONS - SERVICE / SUPPORT DETAILS: 3-Year Advanced Exchange Service and Premium Panel Exchange
HEIGHT WITH STAND (COMPRESSED ~ EXTENDED): 443.76 mm ~ 563.76 mm (17.47” ~ 22.20”)
WIDTH WITH STAND: 894.26 mm (35.21”)
DEPTH WITH STAND: 251.21 mm (9.89”)
HEIGHT WITHOUT STAND: 392.33 mm (15.44”)
WIDTH WITHOUT STAND: 894.26 mm (35.21”)
DEPTH WITHOUT STAND: 102.35 mm (4.03”)
WEIGHT (PANEL ONLY - FOR VESA MOUNT): 8.79 kg (19.37 lb)
WEIGHT (WITH STAND ASSEMBLY AND CABLES): 13.27 kg (29.25 lb)
WEIGHT (WITH PACKAGING): 18.98 kg (41.83 lb)
SECURITY: Security lock slot2 (cable lock sold separately) Anti-theft stand lock slot (to lock stand to monitor using screw)
COMPLIANT STANDARDS:
ENERGY STAR® certified monitor
EPEAT® registered where applicable.
EPEAT registration varies by country
RoHS-compliant
TCO Certified & TCO Certified Edge
BFR/PVC free monitor (excluding external cables)
Arsenic-free glass and Mercury-free for the panel only
FLAT PANEL MOUNT INTERFACEVESA mounting holes (100 mm x 100 mm - behind attached VESA Cover)
FWHAT’S INCLUDED:
Monitor, Stand Riser, Stand Base
1x Power cable1 x DP Cable (DP to DP) - 1.8 m
1x HDMI cable (HDMI-HDMI) - 1.8 m
1x Type-C Gen 2 (C-C cable) - 1 m
1x USB-A to USB-C Gen 2 cable - 1 m
Quick setup guide
Safety, Environmental and Regulatory Information
Factory calibration report
Odkaz na stránky výrobce:
https://www.dell.com/en-us/shop/dell-ultrasharp-38-curved-usb-c-hub-monitor-u3824dw/apd/210-bhsm/monitors-monitor-accessories
