Overview
Dimensions
Without mount: O107.2 x 104.5 x 203.2 mm
(O4.2 x 4.1 x 8")
With mount: O107.2 x 111 x 230.2 mm
(O4.2 x 4.8 x 9.1")
IR Night Vision
30 m (98 ft)
Zoom Mode
10x Hybrid
Face Recognition
?
License Plate Recognition
?
Smart Detections (People, Vehicles, Animals)
?
Resolution
4K
Field of View
Wide: H: 109.9°, V: 56.7°, D: 134.1°
Tele: H: 26.6°, V: 15.1° , D: 30.4°
Pan-Tilt Range
Pan: 350°
Tilt: 100°
Audio
Two-way audio
Weatherproofing
IP66
Tamper Resistance
IK04
Mounting
Wall, Surface, Ceiling, Pole mount (Included)
Corner, In-Ceiling, Pendant mount, Conduit adapter (Optional)
Performance
Networking Interface
10/100 MbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
Max. Frame Rate
30 FPS
Resolution
8MP 3840 x 2160 (16:9)
Optics
Sensor
1/1.8" 8MP
Lens
Wide: F 4.46 mm; f/1.65
Tele: F 16.3 mm; f/2.4
Night Mode
Built-in IR LED illumination and IR cut filter
Hardware
Max. Power Consumption
24.5W
Supported Voltage Range
42.5—57V DC
Power Method
PoE+
Processor
Quad-core Arm® Cortex®-A53 based chip
Pole Mount Diameter
1.5–2" (38–50 mm)
Weight
Without arm mount: 1 kg (2.2 lb)
With arm mount: 1.1 kg (2.4 lb)
Enclosure Material
Aluminum alloy, polycarbonate
Mount Material
Arm mount: polycarbonate
Pole mount: aluminum alloy
Expansion Slot
MicroSD card
Button
(1) Factory-reset
Ambient Operating Temperature
-30 to 50° C (-22 to 122° F)
Ambient Operating Humidity
20 to 90% noncondensing
NDAA Compliant
?
Certifications
CE, FCC, IC
