Overview
Dimensions
O100 x 95 mm
(O3.9 x 3.7")
IR Night Vision
30 m (98 ft)
Face Recognition
?
License Plate Recognition
?
Smart Detections (People, Vehicles, Animals)
?
Resolution
4K
Field of View
H: 109.9°, V: 56.7°, D: 134.1°
Audio
Microphone
Weatherproofing
IP66
Tamper Resistance
IK04
Mounting
Ceiling, wall (Included)
Arm, pendant, junction box (Optional)
Performance
Networking Interface
10/100 MbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
Max. Frame Rate
30 FPS
Resolution
8MP 3864 x 2160 (16:9)
Optics
Sensor
1/1.8" 8MP
Lens
Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter
Hardware
Max. Power Consumption
12.5W
Supported Voltage Range
37–57V DC
Power Method
PoE
Processor
Quad-core Arm® Cortex®-A53 based chip
Weight
550 g (1.2 lb)
Enclosure Material
Aluminum alloy, polycarbonate
Button
(1) Factory-reset
Cable
Cable Connector Type
RJ45
Cable Diameter
4.5 mm (0.2")
Cable Length
30 cm (1 ft)
Jacket Material
Thermoplastic elastomer
Jacket Enclosure Dimensions
O20 x 70.6 mm (0.8 x 2.8")
Jacket Enclosure Material
Thermoplastic elastomer, polycarbonate, silicone rubber
Ambient Operating Temperature
-30 to 50o C (-22 to 122o F)
Ambient Operating Humidity
0 to 90% noncondensing
NDAA Compliant
?
Certifications
CE, FCC, IC
