Ubiquiti Cloud Gateway Fiber (30W)

Overview Dimensions 212.8 x 127.6 x 30 mm (8.3 x 5 x 0.5 ") UniFi Application Suite Network Yes Protect Yes Access Yes Talk Yes Connect Yes Managed UniFi Devices 50+ Managed Cameras (15) HD (8) 2K (5) 4K Simultaneous Users Connected 500+ Default WAN Ports (1) 10G SFP+ (1) 10 GbE RJ45 LAN Ports (1) 10G SFP+ (4) 2.5 GbE RJ45 IDS/IPS Throughput 5 Gbps Form Factor Compact desktop Security Stateful Firewall Yes Application-Aware Layer 7 Firewall Yes DPI & Traffic Identification Yes Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) Yes Content Filtering Yes Intrusion Prevention (IPS/IDS) Yes Ad Blocking Yes IDS/IPS Signatures 55,000+ with CyberSecure VLAN/Subnet-based Traffic Segmentation Yes VPN & SD-WAN License-Free SD-WAN Yes Site-to-Site VPN Site Magic Yes IPsec Yes OpenVPN Yes VPN Server Identity Endpoint One-Click VPN Yes Teleport Zero-Configuration VPN Yes WireGuard Yes OpenVPN Yes L2TP Yes VPN Client OpenVPN Yes WireGuard Yes Networking Multi-WAN Load Balancing Yes Dynamic Routing OSPF Yes Advanced QoS Yes Multicast DNS (mDNS) Yes Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) Yes Integrated RADIUS Server Yes RADIUS over TLS (RadSec) Yes Additional Internet Failover with UniFi LTE Backup Yes Internet Quality and Outage Reporting Yes MAC Address Table Size 4,000 Hardware NVR Storage Selectable NVMe SSD up to 2 TB PoE Budget 30W Max. PoE Wattage per Port by PSE PoE+ 30W Voltage Range PoE Mode 50-57V Max. Power Consumption 29.4W (Excluding PoE output) Power Method DC jack (54V DC/1.1A) Power Supply 54V DC/1.1A (adapter included) Supported Voltage Range 100-240V AC Processor Quad-core ARM® Cortex®-A73 at 2.2 GHz System Memory 3 GB Weight Without SSD: 675 g (1.5 lb) With SSD: 734 g (1.6 lb) Enclosure Material Polycarbonate LCM Display 0.96" status display Management Ethernet Bluetooth LEDs Ethernet Yes SFP+ Yes ESD/EMP Protection Air: ± 8kV, contact: ± 4kV Ambient Operating Temperature 0 to 40° C (32 to 104° F) Ambient Operating Humidity 5 to 95% noncondensing Certifications CE, FCC, IC Button (1) Factory-reset
